    3500g End Of Arm Tooling Grippers

    Ask Lasest Price
    Brand Name : EOAT Grippers
    Model Number : ISC - S Series
    Certification : FDA CE ISO
    Price : USD+($99-$999)+1
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : N+N+per 1 year
    Delivery Time : 2-3 work days
    • Product Details
    • Company Profile

    3500g End Of Arm Tooling Grippers


    EOAT Gripper - ISC S Series


    Product Description

    ISC airbag internal bracing fixture is an innovational soft fixture, designed with inspiration of puffer fish self-defending status. Through inflating air with certain pressure, the airbag can expand and realize internal bracing grasping.Since the contact part with workpiece is soft silicon rubber, after pressurized, an "air matress" can be generated between soft silicon rubber and rigid bracket.


    This makes contact stress uniform and the workpiece is not easy to be damaged. In addition, the pressure of air inflated can be modified to control the range of airbag inflation and contact stress with workpiece. Therefore, flexibility of grasping can be significantly increased.


    Parameter
    Appearance Parameters
    ModelAirbag height HWidth AContact interface diameter DContact interface height BTotal height M
    SRT-ISC-S2336.8232325.5H+105

    Inflation Outer Radius
    ModelNormal diameter(mm)Ultimate expansion diameter(mm)Ultimate air pressure(kPa)Ultimate load(g)
    SRT-ISC-P232334.51803500


    Applications


    The gripper performs handling work in the form of gas expansion, in actual application scenarios, it can be used for bottle-shaped, ring-shaped, objects with holes and highly flexible items, such as glass test tubes, antique vases, drinks in glass bottles and so on.
